low profile radial fans

VRAV-U

Designed for installation in industrial premises, as well as cooling of individual equipment or technological units. It is used in warehouses, in the agricultural sector, in factories and workshops. The equipment features a long service life and does not require complex maintenance.
The fan casing is made of galvanized steel. The casing orientation is 270° to the left. The impeller with forward-curved blades is dynamically balanced in accordance with the ISO 1940 standard. High corrosion resistance thanks to powder coating.

The fan is equipped with single- and three-phase asynchronous motors with a mains supply voltage of 230 V - 50 Hz and 380 V - 50 Hz, respectively.

Design:

  • general purpose industrial (N).
