duct fan with backward-curved blades and side-mounted electric motor

C-KVARK-BC

Designed for use in exhaust systems for moving high temperature ai.

Presence of sticky, fibrous and abrasive components is not allowed, in which the content of dust and other solid impurities should not exceed 0.1 g/m.

Temperature range of the moved medium varies from -30° C to +80° C with high humidity. Upon special request, it is possible to design a version in which the temperature of the moved medium is up to +100° C.
