thermally insulated tandem louvre damper

GMKx2

Designed for passive thermal insulation of the serviced area under conditions of relatively high pressure diff erences.

It is made only of rectangular cross-section.

The GMKx2 damper has a double, highly rigid body designed to protect the damper from distortion during large fl uctuations in average daily temperature.

Design:

  • general purpose industrial (N);
  • corrosion-resistant (CR);
  • explosion-proof (V);
  • explosion-proof corrosion-resistant (CRV).
